Grade 3 Titanium Sheet

Baoji Yinnly Titanium Co., Ltd. is one of the most reliable manufacturers and suppliers of grade 3 titanium sheet in China, featured by high quality customized products. If you're going to wholesale durable grade 3 titanium sheet made in China, welcome to get free sample from our factory. For price consultation, contact us.

Grade 3 titanium sheet (UNS R50550 / TA3) is a medium-strength commercially pure titanium. It contains slightly higher levels of interstitial elements-oxygen and iron-than Grade 1 or Grade 2, which gives it a solid balance of strength, corrosion resistance, and moderate formability. The material is manufactured to standards like ASTM B265 and ASME SB265, and is often chosen for applications that call for better strength than Grade 2 can offer while still needing reliable corrosion protection in low- to medium-stress environments.

Element Ti (Balance) Fe ≤ O ≤ N ≤ C ≤ H ≤

Content Balance 0.30 0.35 0.05 0.08 0.015

• Density: 4.51 g/cm³ - on par with other CP titanium grades
• Tensile Strength: ≥450 MPa, roughly 30% stronger than Grade 2
• Yield Strength: ≥380 MPa, about 38% higher than Grade 2
• Elongation: ≥18%, a bit lower than Grade 2's 20%
• Hardness: ≤180 HB, compared to Grade 2's ≤150 HB
• Corrosion Resistance: Excellent; comparable to Grade 2 and holds up well in seawater, various acids, and chloride environments
• Biocompatibility: Non-toxic and non-reactive with tissue, making it suitable for medical implants
• Weldability: Good results can be achieved with ERTi-3 filler wire under argon shielding

• Chemical & Petrochemical

Used in high-pressure heat exchanger shells, chemical pump impellers, valve bodies, and pipeline flanges. The main draw here is the added strength over Grade 2, combined with good resistance to corrosive media under pressure.

• Marine Engineering

Found in offshore platform structures, seawater pump casings, and deep-sea detector housings. These applications demand both the ability to handle higher stresses and long-term resistance to seawater corrosion.

• Medical Devices

Suited for medium-load orthopedic implants like spinal fixation devices, as well as surgical tool blades. The material balances mechanical strength with the biocompatibility required for medical use.

• Aerospace

Used in aircraft hydraulic system components, engine ducting, and instrument brackets. It's valued here for being lightweight while still offering good strength and corrosion resistance.

• General Industry

Common in high-strength bellows, expansion joints, and pressure vessel liners-anywhere medium-pressure operating conditions call for a dependable material.
