Baoji Yinnly Titanium Co., Ltd. is one of the most reliable manufacturers and suppliers of asme b16.9 titanium tee in China, featured by high quality customized products. If you're going to wholesale durable asme b16.9 titanium tee made in China, welcome to get free sample from our factory. For price consultation, contact us.
Specs and standards
ASME B16.9 Titanium Tee are made to ASME B16.9, and the material requirements follow ASTM B363/SB363 for titanium pipe fittings. Common grades include Gr1 (commercially pure, excellent corrosion resistance), Gr2 (the standard go-to grade), Gr5 (Ti-6Al-4V for higher strength), plus Gr7, Gr11, and Gr12 for more demanding corrosive services.
Size-wise, they go from NPS 1/2" up to 24" (DN15 to DN600), and custom sizes can be made as large as DN1200. Wall thickness options cover Sch5s, Sch10s, Sch10, Sch20, Sch30, Sch40s, STD, XS, and XXS.
Types
- Equal tee: branch diameter matches the main run (seamless construction).
- Reducing tee: branch diameter is different from the main run (welded construction).
You can also get concentric or eccentric reducing tees, depending on how you need the flow aligned.
Manufacturing and quality
Seamless tees are formed by extrusion or bulging, while welded ones use high-precision fusion welding. Forged integral forming gives better structural integrity and mechanical strength compared to welded alternatives. Quality control follows ASME BPVC requirements for safety and reliability-this includes material traceability, dimensional inspection, pressure testing, and NDE methods like X-ray, ultrasonic, and liquid penetrant testing.
Key advantages
Different diameter titanium tees brings a few real benefits to the table. It's lightweight but strong-great strength-to-weight ratio, so it works well in high-pressure or high-temperature systems. Corrosion resistance is outstanding, especially in aggressive environments like chemical plants, desalination, marine applications, or anywhere with acids or chlorides. Plus, it's low maintenance and lasts a long time, which lowers the total lifecycle cost. And because it's built to ASME B16.9, it meets international project specs, so you can use it across borders without trouble.
Typical applications
You'll find these tees in oil and gas (pipelines, refineries, LNG terminals), chemical processing (acid or alkaline fluids, petrochemical reactors), power generation (cooling systems and heat exchangers in thermal or nuclear plants), marine and shipbuilding (seawater systems, offshore platforms), and even pharmaceutical or food processing where hygienic fluid transfer matters-Gr2 or Gr12 are often chosen for cleanability.
